Wireless Connectivity Digital Multimeter Detector MS-WDMMD40
This is a external wireless connectivity Digital Multimeter Detector integrated with 6000 Count, True RMS, auto and manual measurement.
One of the most advantages of the meter is wirelessly connect to Smart phone / Tablet / PC (require different external wireless modules, sold separately) to view data, record reading, capture picture with data on it and send the information to headquarter.
– True RMS
– 6000 counts (3-3/4 digit)
– Auto/manual range
– Large LCD display with backlight
– Auto / Manual ‘V’ (AC / DC) (600V / 1000V)
– ‘μA / mA / 10A (AC / DC)
– Auto/manual resistor measurement : 0 – 60MΩ (approx.)
– Continuity check : <50Ω Beep buzzer sounds
– Capacitance : 10nF – 100mF
– Diode check : 3.0 V
– Input impedance 10MΩ
– ‘NCV’ Non-Contact AC Voltage Detection (Audible and Visible) > 100V
– ‘SPT’ Single Probe Test AC Voltage (Audible and Visible) > 100V
– ‘NCF’ Non-Contact Frequency Detection
– Freeze / Hold reading
– Auto-power off (APO) : 5 mins approx.
– Relative reading (Rel)
– Frequency / Duty cycle (Hz / % ) (10 – 10MHz / 1-99%)
– Max. / Min. / Max. – Min. display
– Lοw battery indication (2.6V approx.)
– Fused test leads tted with replaceable 600mA (Ø6x32mm) and 10A (Ø10x38mm) fast blow fuse (included)
– Standalone mode : without external wireless module.
– Wireless connectivity transmit data to Smart phone/Tablet with iOS APPS or Android APPS(require external wireless module MS-WMB1, sold separately)
– Data logger compatible (require external wireless with memory module MS-WMBM1, sold separately)
– Battery powered : 1 x 9V (6F22 / 6LR61 / 1604)
– Dimension (LxWxD) mm : 179x94x54
– Weight (approx.) grams : 340 (without battery)
